Watec WAT-3200 3GD-SDI Black & White Low Light Camera
The WAT-3200 is a high-sensitivty black and white Full HD 3G-SDI camera with features like white blemish correction, freeze frame, and motion detection. This versatile Watec model is ideal for surveillance, machine vision, and other remote visual inspection applications. Use a variety of CS-mount lenses to achieve the desired fields-of-view.
Specifications
|
Pick-up element |
1/2.8 inch CMOS image sensor |
|
Number of effective pixels |
1945(H) × 1097(V) |
|
Unit cell size |
2.9μm(H) × 2.9μm(V) |
|
Imaging system |
- |
|
Synchronizing system |
Internal |
|
Scanning system |
Progressive |
|
Video output |
3G-SDI, HD-SDI, HD-VLC Composite video: 1.0 V(p-p) 75Ω (Unbalanced) |
|
Resolution (H) |
More than 1000TVL (Center) |
|
Minimum illumination |
0.0001 Iux F1.4 (AGC HIGH=72dB, Shutter=OFF) 0.000007 F1.4 (AGC HIGH=72dB, Shutter=x15) |
|
S/N |
More than 50dB (AGC OFF=0dB, γ=1.0) |
|
Function settings |
OSD : Remote controller, RS-232 (Pelco-D, Pelco-P), Communication: RS-232 (Pelco-D, Pelco-P, Visca) |
|
AE mode |
Fixed: 1/30, 1/60, 1/120, 1/180, 1/240, 1/300 sec. (output format: 60/59.94/30fps) Fixed: 1/25, 1/50, 1/100, 1/150, 1/200, 1/250 sec. (output format: 50/25/24fps) Fixed: 1/500, 1/1000, 1/2000, 1/5000, 1/10000 sec. EI: 1/30 - 1/10000 sec. (output format: 60/59.94/30fps) EI: 1/25 - 1/10000 sec. (output format: 50/25/24fps) EI: x15 - 1/10000 sec. |
|
White balance |
- |
|
Manual Gain Control |
0 - 72dB (5dB step) |
|
Auto Gain Control |
ON: 0 - 72dB (MAX: 0 - 72dB) OFF: 0dB |
|
Day/Night |
- |
|
Gamma characteristics |
γ≒USER (Level adjustable) |
|
Video level |
Adjustable |
|
Noise reduction |
3DNR OFF/ON Level adjustable, 2DNR OFF/ON Level adjustable, 3D+2DNR ON Level adjustable |
|
Wide dynamic range |
WDR OFF/ON Level adjustable, D-WDR OFF/ON Level adjustable |
|
Lens iris |
DC |
|
Backlight compensation |
BLC, HSBLC |
| White Blemish Correction | Up to 2046 pixels |
|
Sharpness |
OFF/ON Level adjustable |
|
Defog |
OFF/ON Level adjustable |
|
Privacy mask |
8 masks |
|
Mirror image |
OFF, V-FLIP, H-FLIP, HV-FLIP |
| Freeze | OFF/ON |
| Motion Detection | OFF/ON 4 areas arbitrarily configurable |
| Neg. Image | OFF/ON |
|
Interface |
BNC (3G/HD-SDI), 2P connector (Composite video), Power in, Auto iris, mini DIN8P (RC-02, RS-232) |
|
Power supply |
DC +12V ±10% |
|
Power consumption |
2.52W (210mA) |
|
Operating temperature |
-10 - +50°C |
|
Storage temperature |
-30 - +70°C |
|
Operating / Storage humidity |
95% RH or less (Without condensation) |
|
Lens mount |
CS mount |
|
Weight Approx |
Approx. 131g |
| Dimensions | 30mm x 30mm x 18mm |
|
Accessories |
WPDC12-R (DC plug), 2P cable, Hex. wrench, camera bracket, RC-02 (Remote control) |
