Canon Medical SV-2000 Video Borescope Inspection System

The Canon Medical SV-2000 Video Borescope Inspection System supports medical device inspection with some of the smallest diameter CMOS video borescopes on the market.

The Canon Medical SV-2000 delivers full-color, high-resolution video from a 400 x 400 pixel CMOS sensor in diameters of 0.89, 1.05, and 1.6 mm. An astonishing 120-degree field-of-view image, fiber optic lighting, and advanced image processing make the SV-2000 a leading inspection tool for finely-machined, manufactured medical components. Achieve quality assurance in delicate catheters, medical tubing, and pacemaker components.

The SV-2000 control unit comes in 2 configurations:

A tablet-based 10-inch touch screen display and control unit
A benchtop control unit with video output via USB 3.0 or HDMI (monitor not included)

The SV-2000 has image recording capabilities, integrated video control software, and complete data management review and playback features. A USB 3.0 and HDMI video allow users to switch outputs between most computers and monitors.

The MagicLight software feature allows the user to touch a portion of the screen during a live inspection for automatic brightness correction.

The SV-2000 is not intended for medical use.

Specifications

EM18418 - SV-2H03X Probe
Scope assembly diameter	0.89 mm
Scope sheath length tip-to-handle mount	1.9 m
Cable length handle mount to CCU	2.0 m
Total cable and sheath length, tip to CCU	3.9 m
LED location	Handle mount
Illumination	LED coupled glass fiber bundle
Sensor Type	CMOS Progressive
Sensor Size (optical format)	0.64 x 0.64 (1/36")
Pixel matrix	400 x 400
Electronic shutter	Rolling
FOV - field of view	120°
Depth of focus	3 to 30 mm
Magnification (depends on viewing distance)	up to 12x
F-number	f 2.8
Focal length	0.175 mm
Water resistance rating	IPX7
Camera head/handle mounting	1/4 - 20 threaded socket
Handle dimensions	85 x 44 x 39 mm (3.3 x 1.7 x 1.5")

EM13076 - SV-2H01N Probe
Scope assembly diameter	1.6 mm
Scope sheath length tip-to-handle mount	1.9 m
Cable length handle mount to CCU	2.0 m
Total cable and sheath length, tip to CCU	3.9 m
LED location	Handle mount
Illumination	LED coupled glass fiber bundle
Sensor Type	CMOS Progressive
Sensor Size (optical format)	1.1 x 1.1 (1/18")
Pixel matrix	400 x 400
Electronic shutter	Rolling
FOV - field of view	120°
Depth of focus	5 to 50 mm
Magnification (depends on viewing distance)	up to 12x
F-number	f 5.0
Focal length	0.418 mm
Water resistance rating	IPX7
Camera head/handle mounting	1/4 - 20 threaded socket
Handle dimensions	85 x 44 x 39 mm (3.3 x 1.7 x 1.5")

EM13077 - SV-2H02N Probe
Scope assembly diameter	1.05 mm
Scope sheath length tip-to-handle mount	1.2 m
Cable length handle mount to CCU	2.0 m
Total cable and sheath length, tip to CCU	3.2 m
LED location	Handle mount
Illumination	LED coupled glass fiber bundle
Sensor Type	CMOS Progressive
Sensor Size (optical format)	0.64 x 0.64 (1/36")
Pixel matrix	200 x 200
Electronic shutter	Rolling
FOV - field of view	120°
Depth of focus	3 to 50 mm
Magnification (depends on viewing distance)	up to 12x
F-number	f 2.8
Focal length	0.175 mm
Water resistance rating	IPX7
Camera head/handle mounting	1/4 - 20 threaded socket
Handle dimensions	85 x 44 x 39 mm (3.3 x 1.7 x 1.5")

EM13078 - SV-2H03N Probe
Scope assembly diameter	0.89 mm
Scope sheath length tip-to-handle mount	1.2 m
Cable length handle mount to CCU	2.0 m
Total cable and sheath length, tip to CCU	3.2 m
LED location	Handle mount
Illumination	LED coupled glass fiber bundle
Sensor Type	CMOS Progressive
Sensor Size (optical format)	0.64 x 0.64 (1/36")
Pixel matrix	400 x 400
Electronic shutter	Rolling
FOV - field of view	120°
Depth of focus	3 to 30 mm
Magnification (depends on viewing distance)	up to 12x
F-number	f 2.8
Focal length	0.175 mm
Water resistance rating	IPX7
Camera head/handle mounting	1/4 - 20 threaded socket
Handle dimensions	85 x 44 x 39 mm (3.3 x 1.7 x 1.5")

EM13075 - SV-2D01N CCU
Display	External (not included)
Touchscreen format	N/A
Output	Simultaneous HDMI, USB 3.0 (UVC)
Output frame rate	30 fps
PC required for use	No
Recorded image formats	.PNG stills, MPEG4 clips
Image record	Image capture to USB media
Key functions	Auto/Manual brightness white balance, calibration
Water resistance rating	None
CCU dimensions	140 x 200 x 43 mm (5.5 x 7.9 x 1.7")
CCU weight	0.95 kg (2.1 lbs)
Mounting	N/A
Power input	12V DC, 0.6A
Environmental	Operating temperature: 10 ° to 35 °C Humidity: up to 75% non-condensing Storage temperature: -20 ° to 70 °C
Included accessories	12V DC power adapter 6’ HDMI cable 6’ USB 3.0 cable type A to type B USB media FAT32 16GB minimum

EM13074 - SV-2T01N CCU/Tablet
Display	Integrated, 10" class touchscreen
Touchscreen format	Capacitive
Output	Switchable HDMI, USB 3.0 (UVC)
Output frame rate	30 fps
PC required for use	No
Recorded image formats	.PNG stills, MPEG4 clips
Image record	Image capture, review, annotation, export/import USB media
Key functions	Auto/Manual brightness Magic Light ROI brightness control white balance, calibration
Water resistance rating	None
CCU dimensions	251 x 48 x 206 mm (9.9 x 1.9 x 8.1")
CCU weight	1.25 kg (2.8 lbs)
Mounting	VESA 75, internal kickstand
Power input	12V DC, 0.6A
Environmental	Operating temperature: 10 ° to 35 °C Humidity: up to 75% non-condensing Storage temperature: -20 ° to 70 °C
Included accessories	12V DC power adapter 6’ HDMI cable 6’ USB 3.0 cable type A to type B USB media FAT32 16GB minimum
