The IMX385 Low-Light 1080p IP Board Camera is a CMOS and encoder combination video capturing solution in the iShot® Miniature Creator Module collection. This powerful module is designed to easily integrate into your existing network and suit a variety of IP-based video surveillance and robotic vision applications.
Key Features:
- Easy IP Management: The module has a default IP address and includes tools like 'IP Cam Search' for convenient IP address modification without needing advanced network knowledge. This feature allows for quick and easy setup and adjustments.
- Flexible Power Options: Supports a wide range of input voltages from 7V to 15V and can be powered either through a PoE switch or a regular DC12V power adaptor, providing versatility in how and where the board camera can be installed.
- High Compatibility: Works seamlessly with various operating systems including Windows 7, 8, 10, and MAC, ensuring that the module can be integrated into virtually any system. It also supports major web browsers such as Internet Explorer 11 or higher, Chrome, Firefox, Safari, and Opera for checking video streams via the web viewer.
- User-Friendly Tools: Includes features such as factory reset and reboot options which are accessible through the 'IP Cam Search' tool, streamlining management and maintenance processes.
- Robust Video Checking: Once connected to your network, video streams can be easily accessed and checked via any compatible web browser by simply entering the device’s IP address. This functionality ensures that users can monitor their video feeds from anywhere at any time.
IP Camera Connection: Connect the IP camera through the RJ45 jack to a router or hub via LAN cable. A regulated DC12V power adapter may be connected directly to the IP camera if not using a PoE switch.
Maximize your monitoring capabilities and enhance security with the IMX385 Low-Light 1080p IP Board Camera from InterTest, Inc., where innovation meets surveillance.
Specifications
| Active Pixels | 2.12MP [1937 (H) x 1097 (V) pixels] |
| Shutter Type | Rolling |
| Scanning System | 16:9 Progressive |
| Minimum Illumination | 0.03Lux (F2.5 - 30IRE), 0.015Lux(ICR on), 0.001Lux (DSS on) |
| Video Output | Up to 30fps @ 1920x1080, 1280x720, 800x600, 704x480, 704x400, 640x480, 640x360, 320x240 |
| Lens Mount | N/A |
| White Balance | AUTO, AUTOext, Preset, Manual |
| Day/Night Mode | Auto, Color, B&W, Ext. |
| Shutter Speeds | 1/25(30)~1/30,000 sec |
| Protocols | TCP/IP, UDP/IP, RTP, RTSP, RTCP, NTP, HPP, DHCP, FTP, SMTP, DNS, DDNS Onvif 17.06 Compatible |
| Video Codec | H.264, MJPEG (Duplex Streaming) |
| Optional Video Output | SDI & Analog (AHD or CVBS) |
| Supply Voltage | DC12V / POE |
| Power Consumption | Less than 5 Watts (320mA, 410mA w/ AF Lens) |
| Operating Temperature | -10°C ~55°C (Humidity: 0% ~ 90% RH) |
| Dimensions | 42mm (W) x 42mm (D) - 2 boards |
| Weight | 23.5g (without OLPF) |
