Description
Details
The KT&C ATC-HZ7810C-A 10x Zoom Rolling Shutter Block Camera is a small 10x multi-output block camera ready to output analog high definition (AHD) or CVBS video.
The KT&C ATC-HZ7810C-A 10x Zoom Rolling Shutter Block Camera uses a 1/2.8" 2.13M pixel Progressive CMOS Image sensor that produces FULL HD 1080p/60fps high-quality images. The sensor uses progressive scanning with a Wide Dynamic Range function to allow the camera to perform in dark and light environments. With low-noise noise imaging from the Noise Reduction function, the KT&C ATC-HZ7810C-A Rolling Shutter Block Camera has both versatilities and high performance.
Other notable features are an automatic Infrared (IR) Cut-Filter for dark environments, motion detection, privacy zone masking, and in-picture text display.
Specifications
|
Video System |
|
|
Image Sensor |
1/2.8" SONY Progressive Scan CMOS |
|
Effective Pixels |
2.13 MP 1945(H) x 1097(V) |
|
Video Output Mode |
|
|
Common |
HD-SDI/EX-SDI(V1.0)/CVBS |
|
AHD / TVI / LVDS |
TVI(T), AVI(A) |
|
Max. Video Resolution |
EX-SDI/TVI/AVI: 1080p@30(25fps) |
|
Synchronization System |
Internal |
|
Min. Illumination |
Day mode: 0.05 Lux(F1.6) Night mode: 0.03Lux(F1.6/ IR-cut filter on) |
|
S/N Rate |
More than 52dB(AGC off, DSS off) |
|
Lens |
|
|
Type |
AF Optical zoom lens(DC Iris), IR Corrective |
|
Focal Length |
f=5.1mm~51mm |
|
F-value |
F1.6(W)~1.8(T) |
|
Angle of View |
Horizontal 54.0°(W)~4.9°(T), Vertical 31.0°(W)~4.0(T)° |
|
Zoom Ratio |
Optical 10x / Digital 12x |
|
Focus Min. Working Distance |
0.01m(Wide)/1.0m(Tele)~∞ |
|
Focus Control |
Auto/Manual/Interval/One Shot/Preset |
|
Exposure |
|
|
AE mode |
Auto/Shutter Priority/Iris Priority/Manual/Bright |
|
Brightness |
0~14 |
|
Manual Shutter |
1/1, 1/2, 1/4(3), 1/8(6), 1/15(12), 1/30(25), 1/60(50)~1/30000 |
|
Manual Iris |
F1.6~F19, Close |
|
Sense-up |
Off~32fields |
|
ETC |
Spot AE, Slow AE |
|
Functions |
|
|
D&N Mode |
Auto/Day(Color)/Night(BW)/External-H or L |
|
White Balance |
AUTO/ATW/Indoor/Outdoor/Push/Manual |
|
Image Freeze |
Off/On |
|
Image Flip |
Off/Horizontal/Vertical/H+V(180° Flip) |
|
Privacy Mask Zone |
16 Zones/14 mask color selectable, semi-transparency |
|
Digital Image Stabilization |
Yes |
|
Motion Detection |
4 Zones |
|
D-WDR |
Off/Low/Middle/High |
|
WDR |
Off/Low/Middle/High |
|
BLC |
Off/On, Area selectable |
|
HLC |
Off/0~20, Color selectable |
|
AGC |
Max.58dB |
|
Sharpness |
Adjustable(0~15) |
|
3D-DNR |
On/Off(1~5) |
|
2D-DNR |
Auto/Manual |
|
Defog |
Off/Low/Middle/High |
|
Preset Position |
256 position Presets(Zoom,Focus), 16 Memory Presets, Custom Preset |
|
Language |
English, Japanese, Russian, Spanish, German, France, Portuguese, Chinese |
|
Communication |
|
|
UART |
|
|
Remote |
RS232 TTL +5.0V(+3.3V compatible) |
|
Protocol |
VISCA/Pelco-D/Pelco-P/Hitachi: Automatic detection |
|
Baud rate |
2400/4800/9600/19200/38400/57600/115200bps |
|
UTC |
TVI(T)-UTC AVI(A)-UTC |
|
Power |
|
|
Supply Voltage |
12VDC(7V to 15VDC) |
|
Power Consumption |
Max.4.2W / Non-working zoom&focus 2.6W |
|
Physical and Temperature |
|
|
Dimension(mm) |
41.6 x45.0 x 61.6mm |
|
Weight |
Approx. 124g |
|
Operating Temperature |
-10℃~+50℃, Humidity(20~80%) |
|
Storage Temperature |
-20℃~+60℃, Humidity(20~95%) |
