Watec WAT-902B EIA CCD Low Light Monochrome Camera

Watec Vendor Logo SKU: EM16899 MFG: WAT-902B EIA

• CAMERA IS END-OF-LIFE; SEE DESCRIPTION TAB FOR REPLACEMENT LINK.
• Compact and lightweight design
• 1/2 inch CCD low light color camera
• Minimum illumination 0.003Lux @ F1.4 (AGC HI)
• Composite Video

Watec

Description

Details

Watec WAT-902B EIA CCD Low Light Monochrome Camera

The Watec WAT 902B EIA 1/2 inch CCD low light color camera has a minimum illumination of 0.003 lux at F1.4 (AGC High). Equipped with Composite Video out, RCA Connection terminal and featuring 2:1 Interlace, 570 TV lines - Center and 380,000 pixels. The Watec WAT-902B features include Shutter speed control, Electronic iris, Flickerless mode, Backlight compensation, and AGC.

The WAT-902H2 Ultimate comes in EIA and CCIR (the black and white versions of NTSC/PAL). This signal used is based on geographic location:

NTSC/EIA = North America, Japan, Korea, Taiwan, South America (Chile, Colombia, Ecuador, Peru, and Venezuela)

PAL/CCIR: Europe, Middle East, India, China, Australia, Argentina, Brazil, Uruguay, Paraguay


PAL region. (2023, January 21). In Wikipedia. https://en.wikipedia.org/wiki/PAL_region

Specifications

Signal System

EIA

Image Sensor

1/2″ B/W IT CCD

Resolution

570 Lines

Number of Pixels

768 x 494

Lens

Accepts CS-mount lenses

Iris Operation

Auto Video

Minimum Illumination

0.003 Lux (F1.4)

Signal-to-Noise Ratio

>50dB

Controls

Electronic Iris

Electronic Shutter

AGC

Gamma Correction

Back Light Compensation

Sync

Internal

Video Output

BNC

Audio Output

No

Motion Detection

No

Alarm I/O

No

Control Ports

N/A

Power Requirements

12 VDC

Power Consumption

1.7W

Operating Temperature

14 – 104⁰F (-10 ~ +40⁰C)

Dimensions

1.4 x 1.4 x 2.3″ (36 x 36 x 58mm)

Weight

3.2 oz (90 g)


Downloads

902B_Manual (73.16 kB)

902B_Spectral (38.87 kB)

watec_wat902b_spec_sheet (103.74 kB)

WAT-902B_Datasheet (597.54 kB)
